Magnetic Drive Pump

• Application
• Other

• Caliber
• 15mm to 50mm

• Capacity
• Up to 20 m3/h m3/hr

• Control System
• Manual or Automatic

• Discharge Pressure
• Up to 2.0 Bar

• Features
• Corrosion Resistant, Leak-Free, Maintenance-Free

• Flow Rate
• Up to 20 m3/h

• Frequency
• 50Hz / 60Hz Hertz (HZ)

• Fuel Type
• Other

• Head Size
• Up to 20 meters

• Inlet/Outlet
• Threaded / Flanged

• Material
• SS304, SS316, SS304L,SS316L

• Max Suction
• 3-4 meters

• Mounting Type
• Horizontal Foot Mounted

• Noise Level
• Low Noise (<70 dB) db

• Power
• Electric

• Pressure
• Medium Pressure

• Priming
• Self-priming not available

• Product Type
• Pump

• Pump Type
• Other, Magnetic Drive Pump

• Seals Type
• Magnetic Driven (Seal-less)

• Speed
• 2900 rpm / 3500 rpm RPM

• Standard
• ISO, CE Certified

• Structure
• Other

• Suction Type
• Flooded Suction or Positive Suction

• Theory
• Centrifugal Pump

• Usage
• Other

• Voltage
• 220V / 380V / Customized/415V Volt (v)

• Working Temperature
• -20C to 120C Celsius (oC)

• Application
• Other, Corrosive Liquids, Acids, Alkalis

• Caliber
• 25 mm

• Capacity
• Variable

• Control System
• Automatic / Manual

• Discharge Pressure
• High Pressure

• Features
• Leak-Proof Operation, Maintenance-Free, Explosion Proof Motor

• Flow Rate
• 3 m3/h

• Frequency
• 50 Hz

• Fuel Type
• Other, Electric

• Head Size
• 25 m

• Inlet/Outlet
• 25 mm / 25 mm

• Material
• PP/PVDF/SS316

• Max Suction
• 5 m

• Mounting Type
• Horizontal

• Noise Level
• <70 dB

• Power
• Other, 1.5 kW

• Pressure
• Other, Max 16 Bar

• Priming
• Self-Priming

• Pump Type
• Other, Magnetic Drive Pump

• Seals Type
• Magnetic Drive (Seal-less)

• Speed
• 2900 rpm

• Standard
• ISO 2858

• Structure
• Other, Single Stage

• Suction Type
• Side Suction

• Theory
• Centrifugal Pump

• Usage
• Other, Chemical Process Industry

• Voltage
• 415 V

• Working Temperature
• -20C to +120C

• Application
• Other, Chemical, Pharmaceutical, Petroleum and Thermal Oil Circulation

• Caliber
• DN32~DN80

• Capacity
• 3 to 100 m3/h

• Control System
• Automatic/Manual

• Discharge Pressure
• 1.0~1.6 MPa

• Features
• Leak-Free, High Safety, Corrosion Resistant, Easy Maintenance

• Flow Rate
• 3 - 100 m3/h

• Frequency
• 50Hz/60Hz

• Fuel Type
• Other, Electric

• Head Size
• 10 - 80 m

• Inlet/Outlet
• 40mm / 32mm

• Material
• High-grade Stainless Steel (SS304/SS316)

• Max Suction
• 6 m

• Mounting Type
• Horizontal

• Noise Level
• 70 dB(A)

• Power
• Other, 1.1 kW - 22 kW

• Pressure
• Other, Up to 1.6MPa

• Priming
• Self-Priming Not Required (Flooded Suction Preferred)

• Pump Type
• Other, Magnetic Drive Pump

• Seals Type
• Magnetic Drive, Sealless

• Speed
• 2900/3500 rpm

• Standard
• GB/T 5656, ISO 2858

• Structure
• Other, Magnetic Coupled, Single Stage

• Suction Type
• End Suction

• Theory
• Centrifugal Pump

• Usage
• Other, High Temperature Liquid Transfer

• Voltage
• 220V/380V

• Working Temperature
• -20C to 350C

• Application
• Other, Chemical, Pharmaceutical, Electroplating, Water Treatment

• Caliber
• 25mm - 80mm

• Capacity
• Up to 60 m3/h

• Control System
• Manual/Auto

• Discharge Pressure
• Max 6 bar

• Features
• Leak-proof, Corrosion-resistant, Maintenance Free

• Flow Rate
• Up to 60 m3/h

• Frequency
• 50Hz/60Hz

• Fuel Type
• Other, Electric

• Head Size
• Up to 38 m

• Inlet/Outlet
• Threaded/Flanged

• Material
• PP, PVDF, Stainless Steel

• Max Suction
• 6m

• Mounting Type
• Vertical

• Noise Level
• <75 dB

• Power
• Other, 0.37 kW - 15 kW

• Pressure
• Other, Up to 6 bar

• Priming
• Self-priming (on request)

• Pump Type
• Other, Magnetic Drive Centrifugal Pump

• Seals Type
• Seal-less (Magnetic Coupling)

• Speed
• 2900 rpm

• Standard
• ISO 9001

• Structure
• Other, Vertical Foot Mounted

• Suction Type
• Vertical

• Theory
• Other, Magnetic Drive Pump

• Usage
• Other, Acid & Alkali Transfer, Chemical Industry

• Voltage
• 220V/380V/415V

• Working Temperature
• -20C to +100C
